水利控制閥（又稱水力控制閥）是一種利用管道中介質（水）自身的壓力作為動力源，通過導閥系統實現自動控制的閥門。其核心原理是通過液壓差動操作主閥的啟閉或調節，無需外部電力或人力干預。以下是其工作原理的詳細分析：

　　Hydraulic control valve (also known as hydraulic control valve) is a valve that uses the pressure of the medium (water) in the pipeline as a power source and achieves automatic control through a pilot valve system. The core principle is to open, close or adjust the main valve through hydraulic differential operation, without the need for external power or human intervention. The following is a detailed analysis of its working principle:

　　1. 基本組成

　　1. Basic components

　　水利控制閥通常由主閥和導閥系統（如針閥、球閥、壓力表、導管等）組成。主閥負責水流的主要通道控制，而導閥系統通過感應壓力、流量或液位變化來調節主閥的動作。

　　Water control valves typically consist of a main valve and a pilot valve system (such as needle valves, ball valves, pressure gauges, conduits, etc.). The main valve is responsible for controlling the main channel of water flow, while the pilot valve system adjusts the action of the main valve by sensing changes in pressure, flow rate, or liquid level.

　　2. 工作原理

　　2. Working principle

　　動力來源：依靠管道上下游的**壓力差（△p）**作為動力。導閥通過感應下游壓力或液位的變化，控制主閥控制室內的壓力介質（水）的進出。

　　Power source: Relying on the pressure difference (△ p) between the upstream and downstream of the pipeline as power. The pilot valve controls the inflow and outflow of pressure medium (water) in the control chamber of the main valve by sensing changes in downstream pressure or liquid level.

　　三種狀態：

　　Three states:

　　開啟狀態：當控制室內的壓力介質被排至下游或大氣時，主閥閥瓣下方的壓力大于上方壓力，閥瓣被推開，閥門開啟。

　　Open state: When the pressure medium in the control room is discharged downstream or to the atmosphere, the pressure below the main valve disc is greater than the pressure above it, the valve disc is pushed open, and the valve is opened.

　　關閉狀態：當控制室壓力介質無法排出時，上方壓力大于下方壓力，閥瓣被壓緊關閉。

　　Closed state: When the pressure medium in the control room cannot be discharged, the upper pressure is greater than the lower pressure, and the valve disc is compressed and closed.

　　調節狀態：控制室壓力介于入口與出口壓力之間時，閥瓣開度由導閥和針閥聯合調節，實現流量或壓力的穩定控制。

　　Adjustment state: When the pressure in the control room is between the inlet and outlet pressures, the valve disc opening is jointly adjusted by the pilot valve and needle valve to achieve stable control of flow or pressure.

　　3. 關鍵機制

　　3. Key mechanisms

　　導閥控制：導閥（如減壓導閥、浮球導閥）根據設定參數（如壓力、液位）自動調整開度，改變控制室壓力。例如：

　　Pilot valve control: Pilot valves (such as pressure reducing pilot valves and float ball pilot valves) automatically adjust their opening based on set parameters (such as pressure and liquid level) to change the pressure in the control room. For example:

　　減壓閥：導閥感應出口壓力，若超過設定值則關閉，使主閥關小以降低壓力。

　　Pressure reducing valve: The pilot valve senses the outlet pressure, and if it exceeds the set value, it closes to reduce the pressure of the main valve.

　　遙控浮球閥：浮球隨液位升降控制導閥啟閉，進而調節主閥開關以維持水位。

　　Remote control float valve: The float valve controls the opening and closing of the pilot valve with the rise and fall of the liquid level, and then adjusts the main valve switch to maintain the water level.

　　隔膜/活塞驅動：主閥通常采用隔膜或活塞結構，將控制室壓力變化轉化為機械動作，推動閥瓣移動。

　　Diaphragm/piston drive: The main valve usually adopts a diaphragm or piston structure, which converts the pressure changes in the control chamber into mechanical action and drives the valve disc to move.

　　4. 功能擴展

　　4. Function expansion

　　通過更換導閥類型或調整附件，水利控制閥可實現多種功能：

　　By changing the type of pilot valve or adjusting accessories, hydraulic control valves can achieve multiple functions:

　　流量控制（如400X型）：通過調節閥瓣開度限制流量。

　　Flow control (such as 400X type): Limit the flow by adjusting the valve disc opening.

　　止回功能（如300X型）：緩閉設計防止水錘，保護管道。

　　Check function (such as 300X type): slow closing design to prevent water hammer and protect pipelines.

　　泄壓/持壓（如500X型）：超壓時自動泄放，低壓時保持設定壓力。

　　Pressure relief/holding (such as 500X type): Automatically release when overpressure occurs, and maintain the set pressure when low-pressure occurs.

　　5. 應用優勢

　　5. Application advantages

　　節能環保：完全依靠水力驅動，無需外部能源。

　　Energy saving and environmental protection: It relies entirely on hydraulic power and does not require external energy.

　　精確可靠：導閥響應靈敏，可精確控制參數（如壓力±0.2MPa）。

　　Accurate and reliable: The pilot valve has a sensitive response and can accurately control parameters (such as pressure ± 0.2MPa).

　　多功能性：一閥多用，適用于供水、消防、灌溉等系統。

　　Multi functionality: One valve for multiple purposes, suitable for water supply, fire protection, irrigation and other systems.

　　示例：遙控浮球閥的工作流程

　　Example: Workflow of remote control floating ball valve

　　初始狀態：浮球閥開啟，控制室無壓力，主閥全開供水。

　　Initial state: The float valve is open, there is no pressure in the control room, and the main valve is fully open for water supply.

　　水位上升：浮球關閉導閥，控制室壓力升高，主閥關閉。

　　Water level rise: The float closes the pilot valve, the pressure in the control room increases, and the main valve closes.

　　水位下降：浮球重新開啟，控制室泄壓，主閥再次開啟補水。

　　Water level drops: The float ball reopens, the control room releases pressure, and the main valve opens again to replenish water.

　　總結來說，水利控制閥通過水力反饋與導閥聯動實現自動化控制，兼具高效性與可靠性，是現代管網系統的核心組件之一。

　　In summary, hydraulic control valves achieve automated control through hydraulic feedback and linkage with pilot valves, combining efficiency and reliability, and are one of the core components of modern pipeline systems.
